FEILONG PU MACHINE
2-Component PU Elastomer Casting Machine (Electric Heating) Precise Ratio Mixing Equipmentfor MDI TDI MOCA System
Main purpose:
Industrial rubber rollers
Screen plates for mining
Hydraulic sealing ring
Photovoltaic guide wheel
Automotive steering shaft ball cup
Phone
+86 13567785285
Quailty Excellence
Core Performance
Excellence QC System
Provide high-quality products and services that exceed customer expectations.
High Scalability
A top-notch industry software development team provides you with first-class service.
Multi-dimensional Support
Professional technical support solutions provided by multiple industries and expert teams
Core Performance
Excellence QC System
Provide high-quality products and services that exceed customer expectations.
High Scalability
A top-notch industry software development team provides you with first-class service.
Multi-dimensional Support
Professional technical support solutions provided by multiple industries and expert teams
Key Attributes
Key Attributes
| voltage | 380 V, Customized | power (w) | 30 kW |
| core components | PLC, Merering pump, Mixed head | machinery test report | Provided |
| warranty | 1 Year | video outgoing-inspection | Provided |
| brand name | FEILONG | place of origin | Zhejiang, China |
| weight (kg) | 2000 | Machine Type | PU elastomer casting machine |
| Produced products | Screen plate,Sealing element,Pipe lining,Wheels,Packing blocks | Material system | MDI,TDI,NDI,PPDI |
| Mixing ratio(MDI) | 100: 50-150 | Mixing ratio(TDI) | 100:6-20 |
| Mixing ratio(NDI) | 100: 2.5-8 | Mixing ratio(PPDI) | 100:80-120 |
| Output | 0.1-500kg/min | Colorable/Additveable | 1 – 20 colors (customizable) |
| Certification | CE/ISO |
A high-temperature type elastomer pouring machine specially designed for the polyurethane elastomer pouring process aimed at enhancing production efficiency. The equipment can meet your current and future process operation requirements.
The head uses an independently developed mixing device (patented technology), and the mixing head adopts a special structure (independently developed), which mixes evenly without bubbles, discharges less, and saves costs; A special balance pressure regulation device (patented technology) can realize different mixing and pouring methods (injection, hose pouring, open pouring), and can also be poured at fixed times and quantities. It can be used for special processes with a wide range of mixing ratios. It can reduce the pressure of material A and increase the pressure of material B to achieve a balanced pressure for thorough mixing: eliminating the flow error of the measurement system, greatly improving the equipment’s measurement accuracy and stability; preventing material A with high viscosity from flowing into the B material pipe, causing blockage;
Three-phase five-wire system with 380V; Frequency: 50Hz;(Voltage can be customized)
Air source: Inlet pipe outer diameter 8mm, pressure 0.4 – 0.6 MPa.
Environmental temperature: Constant temperature control
The installation site has no risk of fire or explosion, and there is no severe vibration.
